Description
• working temperature: from 0°C to 2°C
• refrigerant: R744
• natural defrosting
• 2 x NTC temperature probe
• siphoned condensate drains
• exposition: zinc-plated steel, powder
coated in white (RAL 9003)
• 4 rows of suspended shelves, on shelves
and on air inlet price holders 39 mm
• lighting: top, LEDit, color NW-4
• color of the base – black (RAL 9005)
• grey PVC bumper on the front of the unit
Technical data:
| Modules | 1250 | 1875 | 2150 | 2500 | 3750 | |
| Width* | [mm] | 1250 | 1875 | 2150 | 2500 | 3750 |
| Depth* | [mm] | 970 | 970 | 970 | 970 | 970 |
| Height (±10 mm)* | [mm] | 2100 | 2100 | 2100 | 2100 | 2100 |
| Total Display Area (TDA)* | [m2] | 2,24 | 3,35 | 3,84 | 4,47 | 6,71 |
| Net capacity* | [dm3] | 1040 | 1561 | 1790 | 2081 | 3121 |
| R744-DVO |  |
|
|
|
|
|
| R744-XXX | |
|
|
|
|
|
* for version R744-DVO
Additional settings:
Modules:
1250, 1875, 2150, 2500, 3750
Refrigerant:
R744
Designation of the energy efficiency class is dedicated to a particular products, which are presented on the website. Indicated energy efficiency class depends on a module type, equipment, glassing version and type of a refrigerant. Amendment of each of the said parameters may cause amendment of the energy efficiency class. Contact the producer to acknowledge the energy efficiency class for the product with different parameters to those presented on the website.
